Features:
1. High Definition Imaging: Provides clear and detailed optical imaging for observing small objects, helping children explore and understand the microscopic world.
2. Detailed Observation: The optical design helps capture fine details and textures, making it suitable for science education and curiosity-driven observation.
3. Wide Compatibility: Designed for 1/2.7 inch image sensors, suitable for compatible children's microscopes and compact scanning or imaging devices.
4. Low Distortion: With TV distortion of -0.3%, the lens helps maintain accurate image shapes and clear visual details.
5. M12 Thread Interface: Features an M12 x 0.5 thread for convenient installation with compatible microscope and camera modules.
Specification:
1. Compatible Sensor: 1/2.7 inch sensor
2. Maximum Image Circle: 7.1mm
3. Effective Focal Length: 15.0mm
4. Back Focal Length: 13.6mm
5. Mechanical Back Focal Length: 9.26mm
6. Aperture: F3.73
7. Field of View: Diagonal 22 degrees
8. TV Distortion: -0.3%
9. Chief Ray Angle: Less than 8.2 degrees
10. Relative Illumination: 68%
11. Lens Construction: 2G + IR650
12. Thread: M12 x 0.5
Specification:
|
Package Weight
|
| One Package Weight |
0.01kgs / 0.03lb
|
| One Package Size |
10cm * 8cm * 2cm / 3.94inch * 3.15inch * 0.79inch
|
| Carton Weight |
6.00kgs / 13.23lb
|
| Carton Size |
52cm * 42cm * 42cm / 20.47inch * 16.54inch * 16.54inch
|
| Loading Container |
20GP: 290 cartons * 500 pcs = 145000 pcs
40HQ: 674 cartons * 500 pcs = 337000 pcs
|
|
